TDG product range

TDG PRODUCT CATALOGUES

Do you want to know more about a particular clamping system?

Download your TDG Product Catalogue to get more detailed information related to your enquiry.

Sistemas Amarres Platos Automaticos
Sistemas Amarres Platos Manuales
Sistemas Amarres Intercambiadores Pallets
Sistemas Amarres Tdg Smartchuck

“Our services begin with the most professional advice and continue right up to an attentive after-sales service so that our customers get the chuck they really need. They shouldn’t have to pay a single euro extra for services they don’t require.”

Fernando Santamaría

TDG Sales & Marketing Manager

Fernando Santamaria Tdg Marketing Manager

More than just clamping solutions:
Quality, effectiveness and cost-efficiency

At TDG, we listen to our customers and relish the challenges they bring to us. We analyse their project carefully to make it a reality thanks to a policy of maximum quality based on the following values.

Tdg Creatividad Innovacion

Creativity and innovation

Tdg Relaciones Clientes Proveedores

Customer and supplier relations

Tdg Productividad Eficiencia

Productivity and resource efficiency

Tdg Productos Calidad

Quality

Tdg Productos Implicacion

Commitment

Customize your clamping system with TDG

Our design team specializes in adapting classic clamping concepts to the specific needs of each market: lathe clamping devices, large diameters, special jaws, rotary chucks, mandrels, hydraulic solutions, etc. If you can’t find what you’re looking for, please contact us.

Most popular TDG products

Manual chucks

The best price/performance ratio on the market with the reliability that comes with more than 100 years of experience. Steel chucks of the highest quality with a ground finish. Precision and robustness. Versions for vertical turning lathes (VTL), for applications using big bores and for heavy-duty applications up to 200 tonnes.

Platos Industriales Manuales Tdg
Manual chucks for horizontal or vertical lathes
Heavy-duty manual lathe chucks
Large-diameter combination chucks
Face plates, TDG pallets and box jaws
Platos Industriales Automaticos Tdg

Power chucks

For large automatic applications, from diameters of 630 upwards. Solutions tailored to the customer’s application: 100% customized. Versions for horizontal and vertical lathes, with different numbers and design of jaws and cylinder included and designed for the specific application.

Automatic 3-jaw closed center and through hole chucks
Large-diameter automatic chucks
Customized solutions with automatic chucks
Power chucks with 2+2, 2+2+2 or 3+3 jaw configurations
Sistema Pallets Platos Grandes Tdg

Pallet system

Different palletizing systems for large lathes, from diameters of 630 upwards. Zero-point or hirth coupling technology for maximum precision. Tailor-made for each customer’s machine and application.

TDG rotopallet with centering systems
Rotary pallet exchanger system
Lineal pallet exchanger system
Customized pallet exchangers

Pallet system

Different palletizing systems for large lathes, from diameters of 630 upwards. Zero-point or hirth coupling technology for maximum precision. Tailor-made for each customer’s machine and application.

Sistema Pallets Platos Grandes Tdg
TDG rotopallet with centering systems
Rotary pallet exchanger system
Lineal pallet exchanger system
Customized pallet exchangers

TDG Smartchuck

The perfect safety system for workers offering real-time information on the chuck torque, even remotely. It warns of clamping losses, prevents deformation of the workpiece and produces work comparisons and optimal clamping force studies.

Tdgsmartchuck Sistema Seguridad

TDG Smartchuck has a range of applications, including:

Alert to a possible loss of clamping or loose part
Avoid deformation of the part
Store historical data
Study of optimal clamping forces

TDG has been the exclusive distributor of Kitagawa in Spain for more than 15 years

We have at our disposal a large stock in Gernika and SAT service so that no machine is left standing idle.
These are some of the Kitagawa products available from TDG.

Kitagawa automatic chucks
Steady rests
Kitagawa chuck spare parts
Kitagawa grippers and gripper holders
Kitagawa robotics
Kitagawa cylinders
4th and 5th axis rotary tables
Kitagawa 5-axis tables
Kitagawa grippers

We are also a distributor of Zentra products

Zentra manual chucks
Zentra self-centering chucks
Zentra cast iron chucks

How can we help you?

Tell us what you need. Tell us about your project. At TDG we will get to work to deliver the best clamping solution for your needs.
